OV是全球图像传感器的技术***， 公司成立于1985年， 从早期的30M像素图像传感器开始一直致力于CMOS SENSOR的技术研发和创新。 到目前为止， 开发的图像传感器像素高达50M像素， 广泛应用于 汽车车载，医疗，安防，工控，笔记本电脑和各类消费类电子。

汽车车载电子方面用到的型号：图像传感器

• OV10625







• OV10626







• OV10635







• OV10640







• OV10642







• OV10650







• OV10652







• OV2311







• OV2775







• OV2775-ARDS







• OV7261







• OV7955







• OV9284







• OV9716







• OX01A10







• OX01B40







• OX02A10







• OX03A10







ASIC

• OV480







• OV490







• OV491







• OV493







• OV495







安防领域的图像传感器代理型号

图像传感器

• OS02A1Q







• OS02C10







• OS02F10







• OS04B10







• OS0***10







• OS0***20







• OS08A10







• OS08A20







• OV10823







• OV2710-1E







• OV2715-1E







• OV2718







• OV2732







• OV2735







• OV2736







• OV2770







• OV4685







• OV4686







• OV4689







• OV5658







• OV7725







• OV7740







• OV7850







• OV7960







• OV9623







• OV9674







• OV9712-1D







• OV9715







• OV9718







• OV9732







• OV9750







• OV9752







• OV9755







• OV9756







• OV9760



以及***的紧凑式小尺寸图像传感器 OVM9724

和***适合人脸识别应用的宽动态图像传感器 OV10630 ，OV10633，OV10650

OmniVision&＃39;s ultra-compact OVM9724 CameraCubeChip? captures 720p high definition (HD) video at 30 frames per second (fps) in an industry-leading miniaturized module of 3.9 x 2.9 x 2.3 mm. Because the OVM9724 CameraCubeChip? is a reflowable all-in-one camera drop-in solution, the need for additional components is eliminated and manufacturing is significantly streamlined.

The low-power 1/9-inch OVM9724 utilizes OmniVision&＃39;s powerful OmniBSI?+ pixel architecture to enable high quality color images and fast frame 720p HD video at 30 fps or cropped VGA at 60 fps. This combination of high-performance and small form factor allows HD cameras to be integrated into ultra-slim, narrow-bezel devices, making it an attractive solution for next generation smartphones, tablets, notebooks and Ultrabooks?.

The OVM9724 provides full-frame, sub sampled or windowed 8- and 10-bit images. All required image processing functions, including exposure control and defective pixel cancelling are programmable through the serial camera control bus (SCCB) interface.

Features

MIPI and D-PHY specification (contains one clock lane and one data lane) with a maximum of 400 Mbps data transfer rate

Low operating voltage and low power consumption for embedded portable applications

High sensitivity and low dark current for low-light conditions

Supports global analog gain

Supports free-running clock and gated clock

Supports down sample mode and VarioPixel?

Auto black level calibration

宽动态图像传感器 OV10635  ，OV10640，OV10642

The OV10635 system-on-chip (SoC) sensor raises the standard in automotive imaging by combining megapixel resolution with color HDR. The AEC-Q100 qualified OV10635 comes with a full set of automatic controls and an image processing pipeline for display and sensing applications. Ideally suited for wide field of view and multi-camera applications, the OV10635 also incorporates special features and output formats for automotive machine vision applications. With its proprietary capability to simultaneously deliver high image quality and superior scene information, the OV10635 is designed for automotive applications that perform vision and sensing functions in tandem.

The sensor is built on a 4.2-micron OmniPixel?3-HS pixel, enabling best-in-class low-light sensitivity of 3.65 V/lux-sec to capture detail-rich, high-definition color video in any environment. Using a proprietary new high dynamic range (HDR) concept and processing technology, this automotive sensor delivers excellent scene reproduction in the most demanding lighting conditions, achieving a dynamic range up to 115 dB in color and black-and-white. The OV10635 not only has the ability to accurately reproduce high-contrast scenes, but also employs auto dynamic range control to adjust to changing lighting and scene conditions to produce a clear, detailed and low-noise color image in any automotive situation. A proprietary approach to generating HDR images also dramatically reduces or eliminates many typical HDR image sensor artifacts such as motion ghost artifacts and other unwanted effects.

The OV10635 offers all required automatic image control functions, including automatic exposure control, automatic white balance, automatic black level calibration, as well as defective pixel correction, gamma correction and lens shading correction. The sensor supports a digital video parallel port, and provides full-framed or windowed 10- or 8-bit YUV and 10- to 18-bit combined HDR RAW output format with complete user control over formatting and output data transfer.

Camera functions are programmable through the serial camera control bus (SCCB) interface. Additional features include a horizontal and vertical windowing capability, external frame sync capability, 50/60 Hz flicker cancellation and low power consumption.

The OV10635 comes in a 7.8 mm x 7.1 mm a-CSP? package.
