2SP0320x2Ax-17 Preliminary Data Sheet Compact, high-performance, plug-and-play dual-channel IGBT driver based on SCALE-2 technology for individual and parallel-connected modules in 2-level, 3 level and multilevel converter topologies   Abstract The SCALE-2 plug-and-play driver 2SP0320x2Ax-17 is a compact dual-channel intelligent gate driver designed for 1700V PrimePACKTM IGBT modules. The driver features an electrical interface (2SP0320T) or a fiber-optic interface (2SP0320V and 2SP0320S) with a built-in DC/DC power supply. The turn-on and turn-off gate resistors of both channels are not assembled in order to provide maximum flexibility. They must be assembled by the user before start of operation. Please refer to the paragraph on “Gate Resistor Assembly” for the recommended gate resistors. For drivers adapted to other types of high-power and high-voltage IGBT modules, refer to /go/plug-and-play Features Applications [ Plug-and-play solution [ Allows parallel connection of IGBT modules [ For 2-level, 3-level and multilevel topologies [ Shortens application development time [ Extremely reliable; long service life [ Built-in DC/DC power supply [ 20-pin flat cable interface (2SP0320T) [ Fiber-optic links (2SP0320V & 2SP0320S) [ Duty cycle 0... *** [ Active clamping of Vce at turn-off [ IGBT short-circuit protection [ Monitoring of supply voltage [ Safe ***lation to EN 50178 [ UL compliant [ Suitable for 1700V PrimePACK IGBT modules [ Gate resistors not assembled PrimePACK is a trademark of Infineon Technologies AG, Munich [ Wind-power converters [ Industrial drives [ UPS [ Power-factor correctors [ Traction [ Railroad power supplies [ Welding [ SMPS [ Radiology and laser technology [ Research [ and many others

新型SCALE-2双通道驱动核2SD300C17可替代Infineon的2ED300C17-S，与其管脚和功能完全兼容。它以高可靠性应用为目标。技术优势CONCEPT高度集成的SCALE-2芯片组，所使用的元件比2ED300C17-S减少63%。这样能够***地提高可靠性（通过计算MTBF和测试），并降低成本。2SD300C17具备了双通道驱动核所必需的所有元件及功能，例如隔离的DC/DC电源、短路保护、故障软关机、窄脉冲抑制以及电源电压监控功能。驱动器的原方与副方隔离，两个输出通道之间也隔离。这款驱动器可产生±15 V的门极电压摆幅。每个输出通道都可以提供30 A的输出电流和4 W的驱动功率。EMC性能优异，dv/dt耐受水平超过50 V/ns，即使在要求严苛的工业应用中也能***地运行。

特性

? 兼容Infineon的2ED300C17-S驱动器
? 可提供原厂三防漆涂覆
? 可驱动1700V以内的IGBT
? 开关频率60kHz
? 窄脉冲抑制(400ns)
? 延迟时间<700ns
? 门极电流为±30A
? 门极电压为±15V
? 15V逻辑接口
? 直接模式和半桥模式
? IGBT短路保护功能
? 故障软关断功能
? 隔离的DC/DC电源
? 2 x 4W输出功率
? 电源欠压保护功能
? 符合EN50178安全隔离要求
? 符合UL标准
? 优越的EMC性能
? 性能可靠，工作寿命长

应用
